HDCVI IR Bullet Camera 2MP
CAMERA 2MP
Image Sensor 1/2.7″ CMOS
Effective Pixels 1920(H)×1080(V), 2MP
Scanning System Progressive
Electronic Shutter Speed PAL: 1/25~1/100000s
NTSC: 1/30~1/100000s
Minimum Illumination 0.04Lux/F1.85, 30IRE, 0Lux IR on
S/N Ratio More than 65dB
IR Distance Up to 20m (66feet)
IR On/Off Control Auto / Manual
Lens
Lens Type Fixed lens / Fixed iris
Mount Type Board-in
Focal Length 3.6mm (2.8mm, 6mm Optional)
Max Aperture F1.85
Angle of View H: 93° (103°, 54.7°)
Focus Control N/A
Close Focus Distance 800mm (500mm, 2000mm)
31.5 » (19.69 », 78.74 »)
Remarque: La DORI distance est une « proximité générale » de la distance qui facilite
Identifiez la caméra adaptée à vos besoins. La DORI distance est calculée sur la base de
spécification du capteur et résultat des tests de laboratoire conformément à la norme EN 62676-4 qui définit le critères de détection, d’observation, de reconnaissance et d’identification.
Detect 25px/m 2.8mm: 37m(121ft)
3.6mm: 51m(167ft)
6mm: 80m(262ft)
Video CAMERA 2MP
Resolution 1080P (1920×1080)
Frame Rate 25/30fps@1080P, 25/30/50/60fps@720P
Video Output 1-channel BNC high definition video output / CVBS
video output (Can switch)
Day/Night Auto (ICR) / Manual
OSD Menu Multi-language
BLC Mode BLC / HLC / DWDR
WDR DWDR
Gain Control AGC
Noise Reduction 2D
White Balance Auto / Manual
Smart IR Auto / Manual
Audio Interface N/A
Eelectrical
Power Supply 12V DC ±30%
Power Consumption Max. 2.7W (12V DC, IR on)
Environmental
Operating Conditions -40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH
* Start up should be done at above -40°C (-40°F)
Storage Conditions -40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH
Ingress Protection & Vandal
Resistance IP67
Construction
Casing Aluminium
Dimensions 69.8mm×69.8mm×157.6mm (2.75″×2.75″×6.20″)
Net Weight 0.25kg (0.55lb)
Gross Weight 0.30kg (0.66lb)
Multi-formats
La caméra prend en charge plusieurs formats vidéo, HDCVI, CVBS formats analogiques HD.
